Meet the next generation ofmonsters from Castle Creations!
Castle Creations Mamba MonsterX 2200KV 1:8 Brushless Set / Waterproof ***
Specifications Mamba MonsterX ESC:
-
NEW Sensor Connector
-
NEW MonsterX data logging function
-
NEW Telemetry function
Input voltage: MIN: 2S (7.4V) LiPo / MAX: 6S (22.2V) LiPo
Max . Continuous load: 120A (full throttle or brake with fan)
BEC: 5.5V, 6.0V, 7.5V, 8.0V (adjustable) / 8A peak - default 5.5V
Environment: Waterproof***
Brake: Proportional
Reverse: Yes - with lockout
Dimensions: length: (53mm) Width:(49mm) Height: (34mm)
Weight (without cable): 111.1 grams
Compatible with Futaba T4PX
Technical Data 2200KV Sensor Motor:
Max input voltage: 25.2 volts (6S 22.2V)
Ampere Rating***: 120 Ampere
Max. Speed: 60.000
Weight: 424 grams
Motor Diameter: 39.98mm / 41.78mm (with cooling mills)
Motor length: 75.18mm
Shaft diameter: 5mm
Ball bearing: Oversize ABEC-1 rear & front
Connector: 6.5mm gold contact
Values recordablewithMonsterX Data Logging:
(Link Live mode must be enabled via Castle Link USB Adapter to enable telemetry link communication.Compatible with Futaba T4PX)
- Battery voltage
- Battery power
- Motor power
- Speed
- BEC voltage
- ESC temperature
- Battery Ripple
Values adjustablewith Castle Link USB adapter(optionally available under #010-0005-00 or #010-0063-00):
- Gas curve
- Throttle power
- Brake curve
- Brake power
- Motor timing
- Channel inversion
- LiPo cutoff
- Drag Brake
- Firmawareupdate
- Save / Load controller settings
Scope of delivery:
- Mamba MonsterX 1:8 brushless controller 120A (incl. mounted cooler & on,/off switch)
- 210mm long sensor cable (for sensor controlled driving pleasure)
- Castle Sensor Harness Adapter
- Castle Creations Brushless Inrunner Sensor Motor 1515 2200KV
- Receiver cable (BEC cable) incl. connector (already mounted)
NOTE ***:
The controller and motor are waterproof and can therefore be driven in all weather conditions
. Whether in snow, mud, rain, etc..
However, the regulator and controller are not suitable for driving under water!
Clean/clean the controller and motor after each use with clean water from mud/dirt/spray water etc.
and dry everything completely before you use both again.
The fan of the controller is not waterproof.
Dismantle this when driving in a damp environment!
